- Product Details
TECHNOLOGY PARAMETERS
| Specifications | |||
| Blade diameter | Shank diameter | The slot length | Total length |
| d1 | d2 | L2 | L1 |
| 2.0 | 3 | 12 | 45 |
| 2.5 | 3 | 14 | 45 |
| 3.0 | 3 | 16 | 45 |
| 3.5 | 4 | 20 | 50 |
| 4.0 | 4 | 22 | 55 |
| 4.5 | 6 | 24 | 65 |
| 5.0 | 6 | 26 | 70 |
| 5.5 | 6 | 28 | 70 |
| 6.0 | 6 | 28 | 70 |
| 6.5 | 8 | 31 | 75 |
| 7.0 | 8 | 34 | 75 |
| 7.5 | 8 | 34 | 75 |
| 8.0 | 8 | 37 | 80 |
| 8.5 | 10 | 37 | 85 |
| 9.0 | 10 | 40 | 90 |
| 9.5 | 10 | 40 | 90 |
| 10.0 | 10 | 43 | 90 |
| 10.5 | 12 | 43 | 100 |
| 11.0 | 12 | 47 | 105 |
| 11.5 | 12 | 47 | 105 |
| 12.0 | 12 | 51 | 105 |
Handle can be made according to user requirements (straight shank or sidewall)
3 flutes with symmetrical, suitable for reaming, without reaming
