- Product Details
| Pitch | Blade diameter | Effective length | Blade number | Shank diameter | overall length | |||
| NO | Size and Pitch | PITCH | (d) | (L1) | (F) | (D) | (L) | |
| COARSE | FINE | （MM） | ||||||
| 1 | M7*0.5 | 0.5 | 6 | 10.2 | 3 | 6 | 60 | |
| 2 | M4.5*0.75 | M5*0.75 | 0.75 | 3.6 | 10.1 | 3 | 6 | 60 |
| 3 | M8*0.75 | 0.75 | 6 | 10.8 | 3 | 6 | 60 | |
| 4 | M10*0.75 | 0.75 | 8 | 15.3 | 4 | 8 | 60 | |
| 5 | M5*0.8 | 0.8 | 4 | 10 | 3 | 6 | 60 | |
| 6 | M6*1.0 | M7*1.0 | 1 | 5 | 11.5 | 3 | 6 | 60 |
| 7 | M10*1.0 | 1 | 8 | 17.5 | 4 | 8 | 60 | |
| 8 | M12*1.0 | 1 | 10 | 20.5 | 4 | 10 | 75 | |
| 9 | M8*1.25 | M9*1.25 | 1.25 | 6 | 14.4 | 3 | 6 | 60 |
| 10 | M10*1.5 | M11*1.5 | 1.5 | 8 | 18.5 | 3 | 8 | 60 |
| 11 | M13*1.5 | 1.5 | 10 | 21.8 | 4 | 10 | 75 | |
| 12 | M15*1.5 | 1.5 | 12 | 26.3 | 4 | 12 | 80 | |
| 13 | M20*1.5 | 1.5 | 16 | 35.2 | 4 | 16 | 100 | |
| 14 | M12*1.75 | 1.75 | 10 | 21.8 | 3 | 10 | 75 | |
| 15 | M14*2.0 | 2 | 10 | 25 | 3 | 10 | 75 | |
| 16 | M16*2.0 | 2 | 12 | 27 | 4 | 12 | 80 | |
| 17 | M20*2.0 | 2 | 16 | 37 | 4 | 16 | 100 | |
| 18 | M20*2.5 | 2.5 | 16 | 36.3 | 4 | 16 | 100 | |
| 19 | M24*3.0 | M27*3.0 | 3 | 16 | 40.5 | 4 | 16 | 100 |
| 20 | M27*3.0 | 3 | 20 | 43 | 4 | 20 | 100 | |
